UAD Powered Plug-Ins Manual - 199 - Chapter 15: CS-1 Channel Strip
Recirculation allows both positive and negative values. The polarity refers to
the phase of the delays as compared to the original signal. If Recirculation dis-
plays a positive value, all the delays will be in phase with the source. If it dis-
plays a negative value, then the phase of the delays flips back and forth be-
tween in phase and out of phase.
Damping Knob This low pass filter reduces the amount of high frequencies in the signal. Turn
down this control to reduce the brightness. Higher values yield a brighter sig-
nal. Damping also mimics air absorption, or high frequency rolloff inherent in
tape-based delay systems.
Wet/Dry Mix
Knob
This control determines the balance between the delayed and original signal.
Values greater than 50% emphasize the wet signal, and values less than 50%
emphasize the dry signal.
Wet/Dry Mix allows both positive and negative values. The polarity refers to
the phase of the delays as compared to the original signal. If a positive value
is displayed, then all the delays will be in phase with the source. With a neg-
ative value, the delayed signal is flipped 180 degrees out of phase with the
source.
L-Pan Knob Sets the stereo position for the left channel, allowing you to adjust the width
or balance of the stereo signal. For a mono signal, set both the L-Pan and R-
Pan to the left.
R-Pan Knob Sets the stereo position for the right channel, allowing you to adjust the width
or balance of the stereo signal. For a mono signal, set both the L-Pan and R-
Pan to the left.
Enable/Bypass
Switch
Enables or disables the Reflection Engine. You can use this switch to compare
the RS-1 settings to the original signal or bypass the entire RS-1 section to re-
duce UAD DSP load (load is not reduced if “UAD-2 DSP LoadLock” on
page 74 is enabled).
Output Knob Adjusts the relative output of the plug-in.
