UAD Powered Plug-Ins Manual - 569 - Chapter 57: History
After several unsuccessful attempts at using F.E.T.s in gain reduction circuits, Putnam settled
upon the straightforward approach of using the F.E.T. as the bottom leg in a voltage divider cir-
cuit, which is placed ahead of a preamp stage.
The output stage of the 1176 is a carefully crafted class A line level amplifier, designed to work
with the (then) standard load of 600 ohms. The heart of this stage is the output transformer,
whose design and performance is critical. Its primary function is to convert the unbalanced na-
ture of the 1176 circuit to a balanced line output, and to provide the proper impedance match-
ing to drive the line impedance of 600 ohms. These two jobs are accomplished by the primary
and secondary windings whose turns' ratio defines the impedance ratio.
This transformer is critical due to the fact that it uses several additional sets of windings to pro-
vide feedback, which makes it an integral component in the operation of the output amplifier.
Putnam spent a great deal of time perfecting the design of this tricky transformer and carefully
qualified the few vendors capable of producing it.
The first major modification to the 1176 circuit was designed by Brad Plunkett in an effort to re-
duce noise--hence the birth of the 1176LN, whose LN stands for low noise. Numerous design
improvements followed, resulting in at least 13 revisions of the 1176. Legend has it that the D
and E blackface revisions sound the most “authentic”.
The original Universal Audio 1176LN designed by Bill Putnam was a major breakthrough in
limiter technology – the first true peak limiter with all transistor circuitry offering superior perfor-
mance and a signature sound. Evolved from the popular Universal Audio 175 and 176 vacuum
tube limiters, the 1176LN retained the proven qualities of these industry leaders, and set the
standard for all limiters to follow.
