All rights reserved 187 Service Manual e-Series (EN) 1.1.8
Terminal set for Control Board – 104007
Terminal set for Control Board – 104007
NO.
QTY.
DESCRIPTION
PART NUMBER(S)
PAGE NO.
1
13
Terminals for Control Board
104007
187
2
4
Jumpers for Safety Terminal
N/A
N/A
3
2
Jumpers for external 24V power
N/A
N/A
Return to overview
