NOTICE
Failure to support the joint/s while clamps are removed can result in damage to
equipment.
•
Prevent the joint/s from falling while removing the clamp/s by doing any of
the following:
•
Use something to support underneath the part that is coming off.
•
Disassemble the joint while it is laying down.
•
Support with lifting equipment.
To disassemble:
1. Attach the ESD wristband from the spare part package or tool kit to an electrical grounded
surface.
2. Remove the black flat-ring.
You can use a pair of pointy tweezers or a small flathead screwdriver.
1
3
2
4
3. Remove the screws and the clamp on one side.
UR20 18 Service Manual
Copyright © 2009–2023 by UniversalRobotsA/S. All rights reserved.
