Green/Red permanent = Normal communication
Green slow flash = No communication/trying to establish communication
6.3.2. Fuse
The fuse is a 10A fast-acting mini blade fuse.
CAUTION
Using an inferior fuse can lead to safety hazards.
•
Never use a different fuse than specified. Only use high grade components.
Fuse specifications:
•
Interrupting Rating: 1000A @ 32 VDC
•
Voltage Rating: 32 VDC
•
Component Level Temperature Range: -40˚C to +125˚C
•
System Level Temperature Range: -40˚C to +105˚C
•
Terminals: Ag plated zinc alloy
•
Housing Material: PA66
•
Complies with: SAE J2077, ISO 8820-3
•
UL 248 Special Purpose Fuses
6.4. Complete Rebooting Sequence
To completely reboot the robot system, follow the following steps:
Service Manual 35 UR20
6.Troubleshooting
Copyright © 2009–2023 by UniversalRobotsA/S. All rights reserved.
