MAINTENANCE OF THE MECHANICAL GAS SYSTEM
The main alarm related to the gas system failure is the AF23. Starting from software version 24570
released on June 08th, 2016 that alarm has been split into multiple alarms. Figure 4 shows the meaning
of the various AF23 alarms.
AF23
Cooking
Washing Pre-heating
Flame
detected
AF 23.01
Gas valve
opened at least
one time
Gas valve never
opened
Gas valve
never
opened
Gas valve
opened at least
one time
Gas valve never
opened
Gas valve
opened at least
one time
Flame not
detected
AF 23.02
Flame
detected
AF 23.03
detected
AF 23.04
Flame
detected
AF 23.05
detected
AF 23.06
Flame
detected
AF 23.07
Flame not
detected
AF 23.08
Flame
detected
AF 23.09
Flame not
detected
AF 23.10
Flame
detected
AF 23.11
Flame not
detected
AF 23.12
Figure 4
AF23 gas alarm
When the SD card integrated in the control panel is
corrupted the oven will show a different set of alarms:
■ AF27
AF23.01
■ AF28 AF23.02
■ AF29 AF23.03
■ AF30 AF23.04
■ AF31 AF23.05
■ AF32 AF23.06
■ AF33 AF23.07
■ AF34 AF23.08
■ AF35 AF23.09
■ AF36 AF23.10
■ AF37 AF23.11
■ AF38 AF23.12
When the oven triggers the AF23 alarm, the
display shows you a string of values like X|Y|Z|
W which mean:
■ X = temperature of the cooking chamber when
the alarm triggered;
■ Y = number of times the oven successfully ignited
at the first ignition attempt;
■ Z = number of times the oven successfully ignited
at the second ignition attempt;
■ W = number of times the oven successfully ignited
at the third ignition attempt.
The oven could trigger an AF23.00.
In one of the following modes:
■ door opened;
■ in-between the preheating and cooking step;
■ manual stop of any programs.
Flame not
Flame not
