Unox MINDMaps CHEFTOP User Manual


PE2021A0 sockets

SOCKET
SOCKET TYPE  LABEL DESCRIPTION
P33 STELVIO 6P 1F
1
-
2
3
4 -
5 Heat demand 1 output
6 Heat demand 2 output
P34 STELVIO 3P 1F
1
-
Gas valve power supply - neutral -
(bridge connection)
2
-
3
Gas valve power supply - Phase -
(bridge connection)
P35 STELVIO 3P 1F
1
-
Gas valve power supply - neutral -
(bridge connection)
2 -
3
Gas valve power supply - Phase -
(bridge connection)
P36 STELVIO 3P 1F
1
-
Gas valve power supply - neutral -
(bridge connection)
2 -
3
Gas valve power supply - Phase -
(bridge connection)
P27 RAST-5 3P 1F
1 F_BLW Premix power supply - Phase
2 -
3 N_BLW
Premix power supply - neutral
P29 RAST-5 3P 1F
1 F_BLW Premix power supply - Phase
2 -
3 N_BLW
Premix power supply - neutral
P37
1
BLW1
24VDC
2 Input tachometer blower 1
3
Output control blower 1 - PWM (0-24Vdc) @4kHz
4
GNG (ground connection)
P38
1
BLW2
24VDC
2
Input tachometer blower 2
3
Output control blower 2 - PWM (0-24Vdc) @4kHz
4
GNG (ground connection)
P28 AMP Modu II 6P
1
-
Potentially free contact 1
2
GNG (ground connection)
3
Potentially free contact 2
4
GNG (ground connection)
5
Potentially free contact 3
6
GNG (ground connection)
2
P15 AMP Modu II 2P
1
- Single point core probe input
2
P16 JST XHP-2
1
CMB2
IN
Top temperature probe in oven with
the smoker predisposition)
2 GND
P17
1
DOOR1
IN
Door switch 1 input
2 GND
P18
1
DOOR2
IN
Door switch 2 input(only used in
trolley ovens)
2 GND
MOLEX Minifit
2P
MOLEX Minifit
2P
MOLEX Minifit
4P 2F
MOLEX Minifit
4P 2F
Input flame control board gas alarm
2 Output reset flame control board
3 Protected neutral flame control board
110
