P19 JST XHP-2
1
CMB1
IN
Bottom temperature probe in oven with the
smoker predisposition)
2 GND
P20 AMP Modu II 4P
1
TAC1/2
+13V
Tachometer input TAC1 e TAC2
2
IN_ TAC1
3
IN_ TAC2
4 GND
P30
AMP Modu II
4P
1
TAC3/4
+13V
Tachometer input TAC3 e TAC4
2
IN_ TAC3
3
IN_ TAC4
4 GND
P21
1
21VAC
21V ac
21 V AC power supply from secondary
transformer
2 21V ac
3
12VAC
12V ac
12 V AC power supply from secondary
transformer
4 12V ac
P22
INARLOCK 5P 1F
(Black)
1
- -
2 NGAS
Flame control board power supply - neutral
3 FGAS
Flame control board power supply - phase
4 TSA
Safety thermostat outward
5 TSR
Safety thermostat comeback
P32 JST XHP-2
1
PRES
IN
Pressure switch potential free input
2 GND GND
P24
1
÷ 6
- -
E1
1
E1
Ground connection nut
E2
1
E1
Ground connection nut
Gas power board is equipped with 5 fuses. The function of these fuses are summarized in .
PE2021A0 and PE2021B0 gas board fuses
FUSE
NOMINAL
CURRENT
NOMINAL
VOLTAGE
TYPE PROTECTED CIRCUIT
F2 2A 250V Fast (F) Primary of the transformer (TR60 230V-12V 60VA)
F3 2A 250V Fast (F)
Detergent pump (PD output on P4 socket)
F4 4A 250V Time delay (T) Secondary of the transformer (TR60 230V-12V 60VA)
F7 2A 250V Fast (F) Flame control board BRAHMA ECM113
F9 2A 250V Fast (F) Blowers premix gas
DATA RANGE
Supply Voltage 100/240V-50/60Hz
Operating temperature range -20°C +85°C
Ambient humidity 95% max at 40°C
Protection degree IP 00
Spark Ignition time (TSP) (TS - 1) s
< 1 s
1…60s
Recycling attempts 0..10
MOLEX Minifit
4P
MOLEX Microfit 6P
Fixing Screw
Fixing Screw
European flame control board
The BRAHMA ECM-113 flame control board is equipped with non-volatile lock-out, which means that a
restart from the safety shutdown condition can be accomplished only by a manual reset of the system.
The main technical data are summarized in Table 24.
Table 24 Brahma technical data
Response time in case of flame failure
Lockout time due to parasite flame (Tk)
