REF.
DESCRIP-
TION
SUPPLIER I V F P Q S PF
L
@
R
@
Z
@
DCR X/R
θ
A Contactor
VE1095A0 /
GE– CL01A400T
30
mA
230 V ~ 50 Hz
2 W 6 Var
6.5 Va
0.31
13 H
2 kΩ
9.4 kΩ 770 Ω
4.42
77.2°
B
Solenoid
valve
VE1135A0 /
RPE – SERIE R
30
mA
230 V ~ 50 Hz
4.7 W
4.5 Var
6.5 Va
0.72
9 H
4.7 kΩ 7.4 kΩ 4.3 kΩ
1.19
50°
C Pump
VL1038A0 /
A.R.S. – MPP1
185
mA
140 V ~ 50 Hz
21 W 30 Var
36 Va
0.58
1.75 H
660 Ω
1.3 kΩ
580 Ω
1.66
59°
E Fan
VN1162A0 /
SUNON – DP200A
130
mA
230 V ~ 50 Hz
21 W 19 Var
28 Va
0.75
3.4 H
1.1 kΩ
1.6 kΩ 626 Ω
1.11 48.1°
F Motor
MT1012A0 /
SISME
1.62
240V 60 Hz 388W
- - - -
30.5 kΩ
- - - -
G
DRY.Maxi
solenoid
VE1135-VE1140-
VE1014
RPE SERIES R
-
230V 50 Hz
- - 8VA - - - - - - -
LEGEND
I
Load current consumption
V
Voltage applied to the load
F
Frequency
P
Load active power
Q
Load reactive power
S
Load apparent power
PF
Power Factor (PF=P/S)
@ 100Hz measured inductance
@ 100Hz measured resistance
@ 100Hz measured impedance
DCR
Measured resistance in DC
X/R
Q=|X/R| (X=reactance, R=resistence)
θ
angle between real axis and the impedance vector
Input
NAME
INPUT
DESCRIPTION
INPUT TYPE RANGE
SENSITIV-
ITY
PRECISION
HARDWARE
INPUT
CMB_1
Bottom temperature probe
Analogue PT100
0 – 300 °C
0.1°C +/- 0.5 °C
√
CMB_2
Top temperature probe
Analogue PT100
0 – 300 °C
0.1°C +/- 0.5 °C
√
BRD_TEMP Board temperature probe
Analogue NTC
0 – 100 °C
5°C +/- 5 °C
HEART_1
Mono-point core probe Analogue PT100
0 – 300 °C
1°C +/- 1 °C
√
TAC_1
Tachometer group 1 (speed)
Analogue
30 – 10K RPM
1 RPM +/- 1 RPM
√
TAC_2
Tachometer group 2 (direction)
Analogue
30 – 10K RPM
1 RPM +/- 1 RPM
√
VAC Power supply alternate current
Analogue
0 – 260 VRMS
1 V +/- V
VDC V DC on modbus
Analogue
0 – 15 V
1 mV +/- mV
IDC DC current
Analogue
0 – 7 A
1 mA +/- mA
AC_FREQ Power supply frequency Analogue
0 - 50 - 60 Hz
- -
DOOR_1 Door switch 1 Digital - - -
√
DOOR_2 Door switch 2 (trolley switch) Digital - - -
√
ALL_TS Safety thermostat alarm
Analogue
- - -
ALL_TM Motor thermal protection Digital - - -
