P8
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 1 connection
(MODBUS)
2 GND
3 A
4 B
5 +12V
6 GND
7 GND
8 +13V
P9
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 2
connection (MODBUS)
2 GND
3 A
4 B
5 +13V
6 GND
7 GND
8 +13V
P10
RJ PLUG 8 contacts
90°
1
-
+13V
Accessory board 3
connection (MODBUS)
2 GND
3 A
4 B
5 +13V
6 GND
7 GND
8 +13V
P11 CPM 4P-5P08
1
CONTROL
+13V
Control board connection
(CANBUS)
2 B
3 A
4 GND
P12
1
-
+13V
Bridge board connection
(CANBUS)
2 B
3 A
4 GND
P13
1
-
+13V
Bridge board connection
(CANBUS)
2 B
3 A
4 GND
P28 AMP Modu II 6P
1
-
Potential free contact 1
2 GND
3 Potential free contact 2
4 GND
5 Potential free contact 3
6 GND
2
P15 AMP Modu II 2P
1
- Single point core probe input
2
P16 JST XHP-2
1
CMB2
IN
Top temperature probe
2 GND
P17 MINIFIT 2P
1
DOOR1
IN
Door switch 1 input
2 GND
P18 MINIFIT 2P
1
DOOR2
IN
Door switch 2 input (only
used in trolley ovens)
2 GND
P19 JST XHP-2
1
CMB1
IN
Bottom temperature probe
2 GND
P20 AMP Modu II 4P
1
TAC1/2
+13V
Tachometer input TAC1 e
TAC2
2 IN_TAC1
3 IN_TAC2
4 GND
MOLEX Microfit 4P
MOLEX Microfit
4P
14
