Unox MINDMaps CHEFTOP User Manual

Fuse list
FUSE
NOMINAL
CURRENT
NOMINAL
VOLTAGE
SPEED OF
INTERVENTION
PROTECTED CIRCUIT
F2 2A 250V Fast (F) Primary transformer (TR60 230V-12V 60VA)
F3 2A 250V Fast (F)
Detergent pump (PD output on P4 socket )
F4 4A 250V Time delay (T) Secondary transformer (TR60 230V-12V 60VA)
Mechanical dimensions
DIMENSION X
282 mm
DIMENSION Y
145 mm
MAXIMUM HEIGHT
49 mm
FIXING HOLES
DIAMETER
4,06 mm
Working parameters
PARAMETER MINIMUM VALUE MAXIMUM VALUE
WORKING TEMPERATURE +10 °C +70 °C
STORAGE TEMPERATURE -10 °C +70 °C
WORKING HUMIDITY - 80%
STORAGE HUMIDITY - 90%
Regulations
PE2037A is designed in compliance with the following regulations:
Directive:
73/23/CEE
low voltage: electromagnetic compatibility:
89/336/CEE
General regulations:
CEI EN50081-1
electromagnetic compatibility -
emissions: electromagnetic compatibility -
immunity:
CEI EN50082-1
15
