Input
NAME
INPUT
DESCRIPTION
INPUT TYPE RANGE
SENSITIV-
ITY
PRECISION
HARDWARE
INPUT
CMB_1
Bottom temperature probe
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
CMB_2
Top temperature probe
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
BRD_TEMP Board temperature probe
Analogue NTC
0 – 100 °C 5°C +/- 5 °C
HEART_1
Single point core probe or 1st multi
point core probe point
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
HEART_2 2nd multi point core probe point
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
HEART_3 3rd multi point core probe point
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
HEART_4 4th multi point core probe point
Analogue PT100
0 – 300 °C 0.1°C +/- 0.5 °C
√
TAC_1
Tachometer group 1 (speed)
Analogue
30 – 10K
RPM
1 RPM +/- 1 RPM
√
TAC_2
Tachometer group 2 (direction) Analogue
30 – 10K
RPM
1 RPM +/- 1 RPM
√
VAC Power supply alternate current
Analogue
0 – 260 V
RMS
1 V +/- 5 V
IAC_MOT
Motor power supply alternate
current
Analogue
0 - 8 A
RMS
1 mA
RMS
+/- 50 mA
RMS
IAC_LOAD
Auxiliary loads power supply
alternate current
Analogue
0 - 1.5 A
RMS
1 mA
RMS
+/- 5 mA
RMS
VDC V DC on modbus
Analogue
0 – 15 V 1 mV +/- 20mV
IDC DC current
Analogue
0 – 7 A 1 mA +/- 5mA
AC_FREQ Power supply frequency
Analogue
0 - 50 - 60
Hz
- -
MOTDIR_1
Motor revolution direction
(TAC1-TAC2)
Digital - - -
MOTDIR_2
Motor revolution direction
(TAC3-TAC4)
Digital - - -
DOOR_1 Door switch 1 Digital - - -
√
DOOR_2 Door switch 2 (trolley switch) Digital - - -
√
ALL_TS Safety thermostat alarm
Analogue
- - -
ALL_TM
Motor thermal protection Digital - - -
INCP_1 Potential free contact 1 Digital - - -
√
INCP_2 Potential free contact 2 Digital - - -
√
INCP_3 Potential free contact 3 Digital - - -
√
IN_PRES Pressure switch Digital - - -
√
Communication socket
Power board comes with:
■ 1 CANBUS socket to communicate with the control board (P11)
■ 2 CANBUS sockets to communicate with another power board and with a CANBUS-ETHERNET (P12,
P13)
