Unox MINDMaps CHEFTOP - fuse list; Mechanical dimension; Working parameter; Regulations

Fuse list
FUSE
NOMINAL
CURRENT
NOMINAL
VOLTAGE
SPEED OF
INTERVENTION
PROTECTED CIRCUIT
F2 2A 250V Fast (F) Primary transformer (TR60 230V-12V 60VA)
F3 2A 250V Fast (F) Detergent pump (PD output on P4 socket)
F4 4A 250V Time delay Secondary transformer (TR60 230V-12V 60VA)
Mechanical dimension
DIMENSION X
356 mm
DIMENSION Y
145 mm
MAXIMUM HEIGHT
49 mm
FIXING HOLES DIAMETER
4,06 mm
Working parameter
PARAMETER MINIMUM VALUE MAXIMUM VALUE
WORKING TEMPERATURE +10 °C +70 °C
STORAGE TEMPERATURE -10 °C +70 °C
WORKING HUMIDITY
-
80%
STORAGE HUMIDITY
-
90%
Regulations
PE2038A is designed in compliance with the following regulations:
Directive:
73/23/CEE
low voltage: electromagnetic compatibility:
89/336/CEE
General regulations:
CEI EN50081-1
electromagnetic compatibility - emissions:
electromagnetic compatibility - immunity:
CEI EN50082-1
22
