Unox MINDMaps CHEFTOP User Manual

P31
1
-
+13V
-
2 SR1
3 +13V
-
4 SR2
5 +13V
-
6 GND
P32 JST XHP-2
1
PRES
IN
Pressure switch potential free
input
2 GND GND
P24 1 ÷ 6 - -
E1
Fixing screws
1 E1 Ground connection
Fuse list
FUSE
NOMINAL
CURRENT
NOMINAL
VOLTAGE
SPEED OF
INTERVENTION
PROTECTED CIRCUIT
F2 2A 250 V Fast (F) Primary transformer (TR60 230V-12V 60VA)
F3 2A 250 V Fast (F)
Detergent pump (PD output on P4 socket)
F4 4A 250 V Time delay (T) Secondary transformer (TR60 230V-12V 60VA)
F7 2A 250 V Fast (F) Gas control unit BRAHMA ECM113
F9 2A 250 V Fast (F) Blower gas premix
Mechanical dimensions
DIMENSION X
356 mm
DIMENSION Y
145 mm
MAXIMUM HEIGHT
49 mm
FIXING HOLES DIAMETER
4,06 mm
Working parameters
PARAMETER MINIMUM VALUE MAXIMUM VALUE
WORKING TEMPERATURE
+10 °C +70 °C
STORAGE TEMPERATURE
-10 °C +70 °C
WORKING HUMIDITY
-
80%
STORAGE HUMIDITY
-
90%
Regulations
Reference Guidelines:
73/23/CEE
low voltage:
electromagnetic c ompatibility:
89/336/CEE
General reference rule:
CEI EN50081-1electromagnetic compatibility - emission:
electromagnetic compatibility - immunity: CEI EN50082-1
The PE2021C board has been designed and built in order to fulfill the following legislations:
MOLEX Microfit 6P
MOLEX Microfit 6P
29

Unox MINDMaps CHEFTOP Specifications
