Unox MINDMaps CHEFTOP User Manual

REF. DESCRIPTION ITEM CODE I V F
R

DCR
A Contactor VE1095A0 30 mA 230 V ~ 50 Hz 2 kΩ 770 Ω
B
Solenoid
valve
VE2377A0
30 mA 230 V ~ 50 Hz 4.7 kΩ 4.3 kΩ
E
Cooling
fan
VN1165A0
130 mA 230 V ~ 50 Hz 1.1 kΩ 626 Ω
F Motor MT1012A0 1.62 240V 60 Hz 30.5
G Contactor
VE1095A0
230 V ~ 50-60 Hz
LEGEND
I Absorbed current from load
V
Load vo
ltage
F Line frequency
 Measured value resistance @ 100Hz
DCR DC resistance measured value
Input
NAME
INPUT
DESCRIPTION
INPUT TYPE RANGE RESOLUTION PRECISION
PHYSICAL
INPUT
BRD_
TEMP
Board temperature probe
Analogue NTC
0 – 100°C
(32-212°F)
1°C between
-20 °C and
+80°C (-4F to
176F)
+/- 5 °C
HEART_1
Single point core probe or probe
#1 of multipoint core probe
Analogue PT100
0 – 300°C
(32-572°F)
0.1°C +/- 0.5 °C
√
HEART_2
Probe #2 of multipoint core probe
Analogue PT100
0 – 300°C
(32-572°F)
0.1°C +/- 0.5 °C √
HEART_3
Probe # 3 of multipoint core
probe
Analogue PT100
0 – 300°C
(32-572°F)
0.1°C +/- 0.5 °C
√
HEART_4
Probe # 4 of multipoint core
probe
Analogue PT100
0 – 300°C
(32-572°F)
0.1°C +/- 0.5 °C √
TAC_1
Tachometer group 1 (speed)
Analogue
30 – 10K
RPM
1 RPM +/- 1 RPM
√
TAC_2
Tachometer group 2 (direction)
Analogue
30 – 10K
RPM
1 RPM +/- 1 RPM
√
IAC_MOT Motors AC current absorbed
Analogue
0 - 8 A
RMS
1 mA
RMS
+/- 50
mA
RMS
VDC Direct voltage on bus
Analogue
0 – 15 V 1 mV +/- 20mV
IDC Direct current
Analogue
0 – 7 A 1 mA +/- 5mA
AC_FREQ
Frequency of
voltage line
Analogue
0 - 50 - 60
Hz
- -
MOTDIR
Sense of rotation (from TAC1-
TAC2)
Digital - - -
CP_1
Digital input voltage free contact
# 1
Digital - - -
√
CP_2
Digital input voltage free contact
# 2
Digital - - -
√
ALL_TM Thermal protection alarm Digital - - -
ALL_VAC Line voltage presence Digital - - -
