Communication ports
There are 2 CANBUS ports for communication with the control board and the DC
section inputs (P5, P6)
Feed Line
PARAMETER NOMINAL VALUE MINIMUM VALUE MAXIMUM VALUE
LINE VOLTAGE 230 V
AC
180 V
AC
270 V
AC
LINE FREQUENCY - 50 Hz 60 Hz
List of connectors
CONNECTOR NUME
CONNECTOR
TYPE
PIN
NUMBER
MAXIMUM
VALUE
DESCRIPTION
P1
INARLOCK 6P
2F
(White)
1 N
Auxiliary Board feed (neutral)
2 - Not used
3 - Not used
4 L Auxiliary Board feed (phase)
5 COND Capacitors
6 COND Capacitors
P2
INARLOCK 5P
1F
(White)
1 N
neutral motor group # 2
2 RW Output counterclockwise rotation group motor #2
3 FW Output clockwise rotation group motor #2
4 F 230 Vac Phase motor group # 2
5 TM Motor thermal protection group # 2
P3
INARLOCK 3P
1F
(Black)
1
RES1 Motor Braking element #1 -GROUP # 2
2
2
RES2 Motor Braking element #2 -GROUP # 2
3
P4
INARLOCK 2P
1F (White)
1 V2V Valve output ON-OFF
2 N
Valve neutral
P14
INARLOCK 2P
1F (Black)
1 FAN Auxiliary cooling fan output
2 N
neutral cooling fan
P15
INARLOCK 5P
1F
(White)
1 TL1 TL1 input from PE2038
2 - Not used
3 TL2 TL2 Input from PE2038
4 TSA Safety thermostat input from PE2038
5 TSR Safety thermostat input to PE2038
P16
INARLOCK 5P
1F
(Black)
1 TL1 Phase output contactor # 1
2 N
Contactor neutral output
3 TL2 Phase output contactor # 2
4 TSA
Safety thermostat output
5 TSR Safety thermostat return
