SOCKET
SOCKET TYPE  LABEL DESCRIPTION
P6
INARLOCK
5P 1F
(Black)
1 TL1 Contactor outptut
2 N_F
TL1 neutral
3
4 TSA Safety thermostat outward
5 TSR Safety thermostat comeback
P3
INARLOCK
3P 1F
(Black)
1 RES1 Braking element
2 N_F
Motor neutral
3
P2
INARLOCK
3P 1F
(White)
1 EV1 Output steam solenoid valve
2 N_F
EV1 and VENT neutral
3
P1
INARLOCK
2P 1F
(Black)
1 FAN Cooling fan output - phase
2 N_F Cooling fan output - phase
P7
CPM 2P 1F
(Green)
1 TL1 Contactor output
2 N
TL1 neutral
P9
1
CANBUS1
L
Accessory board 1 connection
(CANBUS)
2 12Vcc
3 GND
4 H
P10
1
CANBUS2
L
Accessory board 2 connection
(CANBUS)
2 12Vcc
3 GND
4 H
P11
1
CANBUS3
L
Accessory board 3 connection
(CANBUS)
2 12Vcc
3 GND
4 H
P12
1
CANBUS4
L
Accessory board 4 connection
(CANBUS)
2 12Vcc
3 GND
4 H
P14 JST XHP-2
1
CMB1
(PT100)
IN
Cooking chamber temperature probe
2 GND
P13
1
DOOR
IN
Door switch 1
2 GND
P15
1
BUZZ
Command 12V
Buzzer output2
3 GND
MOLEX
Microfit
4P
MOLEX
Microfit
4P
MOLEX
Microfit
4P
MOLEX
Microfit
4P
MOLEX Minifit
2P
MOLEX Minifit
3P
44
