Inputs
NAME
INPUT
DESCRIPTION
TYPE OF INPUT RANGE SENSITIVITY ERROR
HARDWARE
INPUT
CMB1 Temperature probe
Analogue
PT100
0 – 300 °C
1°C +/- 1 °C
BOARD Board temperature probe
Analogue NTC
0 – 100 °C
5°C +/- 5 °C
√
VDC
Direct voltage
Analogue
0 - 18Vdc
0,01 V +/- V √
IDC Direct current
Analogue
0 – 5 A
1 mA +/- mA
√
AC_FREQ
Frequency of the network
voltage
Analogue
0 - 50 - 60
Hz
- - √
DOOR Door switch Digital - - -
√
ALL_TS Safety thermostat Digital - - -
√
SYNC
Network sync and motor
thermal protection
Digital - - -
VAC
Power supply
alternate voltage
Analogue
0 – 270 Vac - -
Communication socket
Power board have:
■ 1 canbus socket to communicate with the control board (p09);
■ 3 canbus sockets to communicate with the accessory boards (p10, p11, p12).
Power supply
PARAMETER NOMINAL CURRENT MINIMUM VALUE MAXIMUM VALUE
VOLTAGE POWER SUPPLY 230 VAC 180 VAC 280 VAC
NETWORK FREQUENCY - 50 Hz 60 Hz
Socket table
SOCKET TYPE LABEL DESCRIPTION
P5
INARLOCK 6P
2F
(White)
1 N Board power supply (neutral)
2
3
4 L Board power supply (phase)
5 FW Capacitor for the motor startup
6 RW Capacitor for the motor startup
P4
INARLOCK
5P 1F
(White)
1 N_M Motor neutral
2 RW
Motor power supply -counter clock wise
spinning
3 FW Motor power supply -clock wise spinning
4 L_F Phase 230 Vac
5 TM Motor thermal protection input
