Uplift Desk C-Frame - Frame Assembly - Final Leg Attachment; Step 6 - Leg Assembly Attachment (Part 3)

© UPLIFT Desk • 800-349-3839 • 512-614-3152 • info@upliftdesk.com • upliftdesk.com
9
Step 6 (Continued)
D. Position the other leg assembly onto the Crossbar Rails and repeat the steps above for the other leg.
Note: If your desktop does not have threaded metal inserts or pre-drilled holes, you will need to pre-drill
the holes for this leg assembly at this point as noted in Step 5.
2. Use one screw and washer to fasten the Crossbar
End to the desktop as shown in the image below, do
not tighten completely.
C
T
C
T
C
T
C
T
C
T
E. Tighten all screws installed so far in this step, eight for a C-Frame and six for a T-Frame.
