Section 5
S
CHEMATICS
5.1 I
NTRODUCTION
This section contains electrical and hydraulic power schematics and associated information for maintenance purposes.
The diagrams are to be used in conjunction with the
Troubleshooting Truth Tables
in
Section 4.
They allow understand-
ing of the makeup and functions of the systems for checking, tracing, and faultfinding during troubleshooting analysis.
The components that comprise the electrical and hydraulic systems are given a reference designation and are explained
as to function and location in the following tables.
C
ONTENTS
5.2 Electric - Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
5.3 Hydraulic Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
