Upright X26 Series User Manual

Specifications 504165-002
Operation Manual Page 19
S PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
This machine meets or exceeds all applicable CE and GS machinery directive requirements.
ITEM X26 X32
Platform Size w/ Extension
1,17 m x 2,21 m
[44,25 pulg. x 87 pulg.]
1.17 m x 2.21 m
[44 in. x 87 in.]
Max. Platform Capacity
Standard 454 kg [1000 lb] 340 kg [750 lbs.]
on Extension 113 kg [250 lb] 113 kg [250 lbs.]
Max. No. of occupants
Standard (total) 4 personas
2 personas en el exterior
3 people
on Extension 1 persona 1 person
Height
Working Height 9,93 m [32,58 pies] 11.6 m [38.1 ft.]
Max. Platform Height 7,93 m [26 pies] 9.75 m [32 ft.]
Min. Platform Height 1,09 m [43 pulg.] 1.22 m [48 in.]
Dimensions
Weight 2153 kg [4747 lb] 2486 kg [5481 lbs.]
Overall Width 1,22 m [48 pulg.] 1.22 m [48 in.]
Overall Height 2,19 m [83,5 pulg.] 2.32 m [88.5 in.]
Overall Height, Rails Lowered 1,98 m [78 pulg.] 1.88 m [74 in.]
Overall Length, Extension In 2,35 m [92,5 pulg.] 2.35 m [92.5 in.]
Overall Length, Extension Out 3,26 m [128,5 pulg.] 3.26 m [128.5 in.]
Drivable Height 7,93 m [26 pies] 9.75 m [32 ft.]
Drive Speed
Platform Lowered 0 to 3,2 km/h [0 to 2.0 mph]
Platform Raised 0 to 1 km/h [0 to 0.62 mph]
Energy Source
24 Volt Battery Pack (4-220 A Hour, 6 Volt Batteries, min. wt. 28.12 kg
[62 lbs.] each)
Motor 24 Volt 4 Horse Power DC Electric Motor
System Voltage 24 Volt DC
Battery Charger 25 A, 110/220 V AC
Battery Duty Cycle 25% for 8 Hours
Hydraulic Tank Capacity 15 L [4 US Gallons] 19 L [5 US Gallons]
Maximum Hydraulic Pressure 207 bar [3000 psi]
Hydraulic Fluid
Normal Temperature (>32° F [0° C])
ISO #46
Low Temperature (<32° F [0° C])
ISO #32
Extreme Temperature (<0° F [-17° C])
ISO #15
Lift System
One Single Stage
Lift Cylinder
Two Single Stage
Lift Cylinders
Lift Speed Raise, 45 sec./Lower 40 sec. Raise, 65 sec./Lower 40 sec.
Control System
Proportional Control Handle with Interlock Switch, Rotary Drive/Lift Switch,
and Red Mushroom EMERGENCY STOP Switch
Drive System Dual Front Wheel Hydraulic Motors
Tires 381 mm [15 in.] Diameter Solid Rubber, non-marking
Parking Brake Dual Spring Applied, Hydraulic Release
Turning Radius 203 mm [8 in.] Inside
Maximum Gradeability 12° [22%] 12° [22%]
Wheel Base 1.9 m [74.75 in.]
Guardrails 1.02 m [40 in.] High
Noise Level

Upright X26 Series Specifications

General

Brand	Upright
Model	X26 Series
Category	Scissor Lifts
Language	English
