Upright X26 Series - Controls and Indicators

Controls and Indicators 504165-002
Operation Manual Page 5
C ONTROLS AND I NDICATORS
Figure 2: Controls and Indicators
1
234
Chassis Controls
1Drive Selectors
2. Horn Button
3. Lift/Lower Button
4. Emergency Stop Button
5. Display
6. Joystick
1. Keyswitch
2. Enable Button
3. Toggle Switch (Up & Down)
4. Emergency Stop Switch
Platform Controls
1
3
4
6
2
5
