ITEM NO. PART NO. DESCRIPTION QTY.
— (see chart) Spindle Assembly, crosscut, stainless steel, (includes items 1–19) ...... 1
— (see chart) Spindle Assembly, crosscut, crinkle, (includes items 1–19) ........... 1
1 (see chart) Knife, straight cut ..................................... *
(see chart) Knife, crinkle cut ..................................... *
2 (see chart) Spindle, (includes item 3)................................ 1
3 (see chart) Bearing Block ..................................... 2
4 (see chart) Crank Bearing Block .................................. 1
5 12110 Hex Head Screw ..................................... †
6 12102 Crank Pin.......................................... ‡
7 13293 Drive Cap.......................................... 1
8 12103 Idler Pin, (includes item 9) ............................... ‡
9 12285 Retaining Ring ..................................... 1
10 13070 Gear, 32 teeth, stainless steel, (includes item 11) ................. 1
11 13061 Bearing, for 13070 gear ............................... 1
12 11402 Grease Fitting, 1/8", 65° ................................ 1
13 10094 Socket Head Cap Screw, 1/4-20 x 1" ........................ 3
14 10090 Socket Head Cap Screw, 1/4-20 x 5/8"....................... 3
15 13074 Shaft, crosscut spindle ................................. 1
16 13046 Eccentric, with roll pin, (includes item 17) ..................... 1
17 12105 Roll Pin, 1/4 x 1-1/2" ................................. 1
18 13292 End Cap........................................... 1
19 11403 Grease Fitting, 1/8", 90° ................................ 1
†Two (2) hex head screws required for each knife.
‡ One (1) crank pin and one (1) idler pin required for each knife.
PARTS
Crosscut Knife Spindle Assembly (7, 8, 10, 12, 14, & 16 Knives)
Size Assembly Item 1 Item 2 Item 3 Item 4
of Cut Number Knife Spindle with Bearing Block Crank Bearing
inch mm Straight Crinkle Straight Crinkle Qty. Bearing Blocks Only Block
3/8 (9.5) 13322 14051 12283 12284 16 13321 13058 13052
7/16 (11.1) 13330 14052 12283 12284 14 13329 13057 13051
1/2 (12.7) 13299 14053 13144 14027 12 13298 13054 13048
5/8 (15.9) 13331 14055 13144 14027 10 13301 13155 13154
3/4 (19.1) 13612 — 13144 — 8 13613 13615 13616
7/8 (22.2) 13334 14054 13144 14027 7 13333 13055 13049
