USC LPH800 - Section C; Mechanical Operation; System Overview

Page 18
LPH800 TREATER
SYSTEM OVERVIEW
Mechanical Operation
Section
C
Atomizer
Chamber
30 - Gallon
Mix Tank
Rotating
Drum
Inoculant
Tank
Adjustable
Seed Flow
Gate
Adjustable
Legs
Calibration
Tube
Pump #1 Peristaltic
Pump 6-600 Motor
& L/S Pump Head)
Peristaltic Pump
(1/4 HP Leeson Pump
Motor, I/P Pump Head, &
Speed Reducer, )
OR
Conveyor
Receptacles
Filter
Pump #2
Inoculant
Tank
12” Extension Ring
Discharge
Chute
Treater
Control
Panel
Quick
Release
Atomizer
Chamber
Handle
