USC LPH800 - Pump Charts

Page 36
LPH800 TREATER
Standard Data
Below are two charts that show the potential volts and oz / min of two different pumps
at different dial settings.
All calibrations were done using water. Numbers are not exact,
only use these numbers as a starting point or for
troubleshooting.
Volts OZ./Min.
10.5 7.4
14.6 10.5
18.8 14.1
22.9 17.7
27.0 21.3
31.2 24.9
35.3 28.5
39.4 32.1
43.6 35.7
47.7 39.3
51.8 42.9
55.9 46.5
60.1 50.1
64.2 53.7
68.3 57.3
72.5 60.9
76.6 64.5
80.7 68.1
84.9 71.7
89.0 75.3
6-600 RPM Motor and
L / S Pump Head with
Masterflex L / S 35 Pump Tubing
Volts OZ./Min.
9.2 22.6
13.3 36.3
17.5 50.0
21.6 63.7
25.8 77.4
29.9 91.1
34.1 104.8
38.2 118.5
42.3 132.2
46.5 145.9
50.6 159.7
54.8 173.4
58.9 187.1
63.0 200.8
67.2 214.5
71.3 228.2
75.5 241.9
79.6 255.6
83.8 269.3
87.9 283.0
1725 RPM Motor, 4.8:1 Reducer
and I / P Pump Head with
Masterflex I/P 82 Pump Tubing
NOTICE
