Page 39
LPH800 TREATER
The Illustration below shows how seed passes through the atomizing chamber.
The red represents treatment being dispensed to the seed as it passes through the
chamber. After the seed passes through the atomizer, it goes into the drum where
the coating process is completed.
Conversion Chart
1 ounce = 29.58 milliliters
1 gallon = 3.79 liters
1 kilogram = 2.2 pounds
1 unit = 50 lbs or 22.73 kg
1 bushel = approx. 60 lbs or 27.27 kg
1 cwt = 100 lbs or 45.45 kg
TREATING SEED
Atomizer
Head
Distribution
Cone
Bearing
Inoculant
Port
Seed
Treatment
Line
Seed Gate
Atomizer
Chute
Atomizer
Motor
