LPH800 TREATER
LPH800 BASE FRAME ASSEMBLY (18-01-0011)
Item # Part #
Descripon Qty
1 01-01-0101
GBOX IL 56C 16.2:1 GR B1 FOOT MNT 1
2 01-02-0093 SPROCKET # 50 14T 1.00 IN BORE TYPE B 4
3 01-02-0095 SPKT 17 T 50P .500 ID IDLER 2
4 01-03-0036 BRG PLW 1.00ID STSC SEALED 6
5 01-04-0005 #50 CNTG LINK 2
6 01-05-0008 SHAFT CLR 1.00ID SPLIT 8
7 01-06-0002 WHL DRV 6 X 2 X 1.00ID .250KWY 4
8 01-10-0003 KEY .250 X 2.00 CS 4
9 01-10-0004 KEY .250 X 1.00 CS 4
10 05-04-0067 WDMT DRUM DRV ADJ PLT 1
11 05-11-0003 DRUM DRIVE SHAFT LPX 2
12 06-01-0026 BOLT CRG .500-13 X 2.00 ZP GR5 1
13 06-01-0027 BOLT .500-13 X 2.00 ZP GR5 1
14 06-01-0029 BOLT .500-13 X 3.25 ZP GR5 12
15 06-01-0137 BOLT .375-16 X 2.00 ZP GR5 FULL THRD 2
16 06-01-0172 BOLT CRG .313-18 X 1.75 ZP GR5 4
17 06-02-0003 NUT FULL .375-16 ZP GR5 2
18 06-03-0015 NUT LOCK FLG .500-13 ZP GR5 14
19 06-03-0019 NUT, FLG .3125-18 UNC ZP GRADE 5 4
20 13-05-0156 #50 CHAIN 84LINKS 1
21 13-05-0157 #50 CHAIN -- 32 LINKS 1
22 18-01-0007 WDMT BASE FRAME LPX 1
