2LV/2L1/2L2/2MS/2MT-1
1-2-10
1. Open the rear cover.
2. Remove the inlet cover.
3. Connect the USB interface cable to the
printer and PC.
Figure 1-2-18
4. Connect the network interface cable to
the printerand network.
Figure 1-2-19
5. Connect the power cord to the printer
and the wall outlet.
6. Refit the inlet cover.
7. Close the rear cover.
Figure 1-2-20
Connecting the cable
USB interface cable
Inlet cover
Network
interface cable
Power cord
Wall outlet
