UTICA BOILERS USC - Replacement Parts: Flue Collector and Venter; Flue Collector and Venter Assembly Parts

USC SERIES REPLAUSC SERIES REPLA
USC SERIES REPLAUSC SERIES REPLA
USC SERIES REPLA
CEMENT PCEMENT P
CEMENT PCEMENT P
CEMENT P
ARAR
ARAR
AR
TSTS
TSTS
TS
FLFL
FLFL
FL
UE COLLECTUE COLLECT
UE COLLECTUE COLLECT
UE COLLECT
OR & OR &
OR & OR &
OR &
VENTER COMPONENTSVENTER COMPONENTS
VENTER COMPONENTSVENTER COMPONENTS
VENTER COMPONENTS
PAGE 24
FIGURE 26
ITEM # PART # DESCRIPTIONS QTY.
1 3472501 FLUE COLLECTOR ASSY USC3 1
3472502 FLUE COLLECTOR ASSY USC4
3472503 FLUE COLLECTOR ASSY USC5
2 345-2-7.01 VENT ADAPTER 1
3 HW-005.01 SCREW 1/4-20X1/2 SELF TAP 5
4 DC00402 VENTER USC - MAGNETEK 1
5 3571501 GASKET - VENTER USC 1
6 HW09501 BOLT 5/16"-18X1.1/2" TYPE F 2
