8
II System and Operation
II Uwatec
®
Smart dive computers
1 System Description
The Smart displays all important dive and decompression data.
The Smart has a data memory, which stores the dive data. The data can be transmitted with the standard
infrared interface (IrDA) and the SmartTrak software to a Windows
®
personal computer. The SmartTrak CD
software is included with the SmartTrak Package. Infrared interfaces are available in PC-stores.
A list of recommended interfaces is available on the Uwatec homepage (www.uwatec.com).
2 Operation
On page 5 you will find an operating schematic.
2.1 Operating Elements
The Smart has 4 operating contacts B, E, +, – on the outside of the housing. For manual operation, touch
base contact B and any one of the other three contacts above the display with moistened fingers.
Contact B:
Base contact, which has to be touched for all operations.
In order to keep the text as simply as possible, it will no longer be pointed out
that the contact B must be touched every time.
Contact E:
Enter contact. It serves to switch on the Smart
and to confirm or enter the displayed value. It
is therefore comparable to the ENTER- or
RETURN-key of a computer.
+ / – Contacts:
At the surface you can select with these
contacts the dive planner, the logbook and the
functions to adjust the O
2
% mix and the
Microbubble-Level. See page 9.
Once inside the function the + increases the
indicated value and the – reduces it.
