52
• Fit the rear securing bolts (45/1) and (45/2)
In delivery condition the mounting
bolts are already fitted.
• Disconnect the plug connector X24 on the lead
of the body fan (46/1) and the BREEZE hose
coupling (46/2)
• Detach the body fan mounting (47/1+2)
• Pull through the body fan lead (48/2) complete
with plug
X24 and the BREEZE hose complete with
coupling (48/1)
