59
Prerequisite:
All high pressure lamp modules and the cantilever arm
are demounted
Secure the stand against falling over!
• Remove the top right screw (74/1) and
bottom right screw (74/2)
• Remove the top left screw (75)
• Remove the bottom left screw (76/1)
Detachment of the stand from the base frame
