V2 AZIMUT Instruction Manual

ENGLISH
11
TECHNICAL SPECIFICATIONSINDEX
DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . .11
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . .11
IMPORTANT REMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PRELIMINARY CHECKINGS . . . . . . . . . . . . . . . . . . . . . . . . . . .13
INSTALLATION LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
I
NSTALLATION OF GUIDE SECTION BAR . . . . . . . . . . . . . . . . . .14
INSTALLATION OF MOTOR ON SECTION BAR . . . . . . . . . . . . . .15
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
RELEASE OF THE AUTOMATION . . . . . . . . . . . . . . . . . . . . . . .16
ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . .16
SET-UP OF OPERATIONAL PARAMETERS . . . . . . . . . . . . . . . . . .17
MEMORISING REMOTE CONTROL UNITS . . . . . . . . . . . . . . . . .20
DELETING REMOTE CONTROL UNITS . . . . . . . . . . . . . . . . . . . .20
EC DECLARATION OF INCORPORATION FOR
PARTLY COMPLETED MACHINERY
(Directive 2006/42/EC, Annex II-B)
The manufacturer V2 S.p.A., headquarters in
Corso Principi di Piemonte 65, 12035, Racconigi (CN), Italy
Under its sole responsibility hereby declares that:
the partly completed machinery model(s):
AZIMUT, AZIMUT-120V
Identification number and year of manufacturing: typed on
nameplate
Description: electromechanical actuator for garage doors
- is intended to be installed on garage doors to create a machine
according to the provisions of the Directive 2006/42/EC.
The machinery must not be put into service until the final
machinery into which it has to be incorporated has been declared
in conformity with the provisions of the Directive 2006/42/EC
(annex II-A).
- is compliant with the applicable essential safety requirements
of the following Directives:
Machinery Directive 2006/42/EC (annex I, chapter 1)
Low Voltage Directive 2006/95/EC.
Electromagnetic Compatibility Directive 2004/108/EC.
Radio Directive 99/05/EC
The relevant technical documentation is available at the national
authorities’ request after justifiable request to:
V2 S.p.A., Corso Principi di Piemonte 65,
12035, Racconigi (CN), Italy
The person empowered to draw up the declaration and to provide
the technical documentation:
Cosimo De Falco
Legal representative of V2 S.p.A.
Racconigi, 11th January 2010
AZIMUT AZIMUT-120V
Power supply 230Vac - 50Hz 120Vac - 60Hz
Absorbed power 100W 100W
Lamp 230V - 25W 120V - 25W
Protection fuses
SOURCE = 2,5A
LIGHT = 2,5 A
SOURCE = 2,5A
LIGHT = 2,5 A
Door area < 8m
2
< 8m
2
Average speed 110mm/s 110mm/s
Peak force 500N 500N
Nominal force 350N 350N
Working temperature -20 ÷ +40 °C -20 ÷ +40 °C
Rated Operating Time > 4 min. > 4 min.
Protection degree IP20 IP20
Weight 10Kg 10Kg

V2 AZIMUT Specifications

General

Brand	V2
Model	AZIMUT
Category	Controller
Language	English
