7. GENERAL DATA
Dimensions
and weight
Frame Height (mm) Width (mm) Depth (mm) Weight (kg)
MI1 160 66 98 0.5
MI2 195 90 102 0.7
MI3 254 100 109 1
Supply
network
Networks Vacon 10 (400 V) cannot be used with corner grounded networks
Short circuit cur-
rent
Maximum short circuit current has to be < 50 kA
Motor
connection
Output voltage
0 - U
in
Output current
Continuous rated current I
N
at ambient temperature max. +50 ºC
(depends on the unit size), overload
1.5 x I
N
max. 1 min / 10 min
Ambient
conditions
Ambient operat-
ing temperature
-10 °C (no frost)…+40 / 50 °C (depends on the unit size): rated load-
ability I
N
Side by side installation for MI1-3 it is always 40 °C; For IP21/
Nema1 option in MI1-3 the maximum temparture is also 40 °C
Storage temper-
ature
-40 °C…+70 °C
Relative humid-
ity
0…95% RH, non-condensing, non-corrosive, no dripping water
Altitude
100% load capacity (no derating) up to 1000 m. 1% derating for
each 100 m above 1000 m; max. 2000 m
Enclosure class IP20 / IP21 / Nema1 for MI1-3
Pollution degree PD2
EMC
Immunity Complies with EN50082-1, -2, EN61800-3
Emissions(See
detailed descrip-
tions in Vacon 10
User Manual at:
www.vacon.com)
230V: Complies with EMC category C2; With an internal RFI filter
400V: Complies with EMC category C2; With an internal RFI filter
Both: No EMC emission protection (Vacon level N): Without RFI filter
Standards
For EMC: EN61800-3
For safety: UL508C, EN61800-5
Certificates
and manu-
facturer’s
declara-
tions of
conformity
For safety: CE, UL, cUL
For EMC: CE
(see unit nameplate for more detailed approvals)
