Vacon 100X - Page 11

4.1.1.2 Dimensions of the the wall-mounted drive with the marine option, MR5
17 (0.67)
441 (17.36)
406 (15.98)
144 (5.67)
214 (8.43)
115 (4.53)
4 x Ø6
(0.24)
Fig. 3: Dimensions of the wall-mounted drive with the marine option, MR5, [mm (in)]
MOUNTING VACON · 11
