4.1.1.3 Dimensions of the the wall-mounted drive with the marine option, MR6
17 (0.67)
576 (22.68)
540 (21.26)
195 (7.68)
229 (9.06)
148 (5.83)
4 x Ø8
(0.31)
Fig. 4: Dimensions of the wall-mounted drive with the marine option, MR6, [mm (in)]
