3 MR9-MR12: To attach the upper damper, use:
A)
An M12 x 30 mm bolt tightened to a 60-70 Nm
torque
B)
A 12 mm plain washer
C)
An M12 nut tightened to a 60-70 Nm torque
B
C
A
