Vacon 20 Quick Guide

monitoring & parameters vacon • 23
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
5
V3.1 Drive status word 43
Bit codes status of drive
B0 = Ready
B1 = Run
B2 = Reverse
B3 = Fault
B6 = RunEnable
B7 = AlarmActive
B12 = RunRequest
B13 = MotorRegulatorActive
V3.2 Application status word 89
Bit codes status of application:
B3 = Ramp 2 Active
B5 = Remote CTRL Place 1 active
B6 = Remote CTRL Place 2 active
B7 = Fieldbus Control Active
B8 = Local Control Active
B9 = PC Control Active
B10 = Preset Frequencies Active
V3.3 DIN status word 56
B0 = DI1
B1 = DI2
B2 = DI3
B3 = DI4
B4 = DI5
B5 = DI6
B6 = DIE1
B7 = DIE2
B8 = DIE3
B9 = DIE4
B10 = DIE5
B11 = DIE6
V4.1 PID set point % 20 Regulator setpoint
V4.2 PID feedback value % 21 Regulator actual value
V4.3 PID error % 22 Regulator error
V4.4 PID output % 23 Regulator output
V4.5 Process 29
Scaled process variable
see par. 15.18
Code Monitoring signal Unit ID Description
Table 4: Monitoring values

Vacon 20 Specifications

General

Communication Options	Modbus, CANopen, PROFIBUS, Ethernet
Protection Class	IP20
Power Range	0.25 to 18.5 kW
Control Method	Scalar control, Vector control
Ambient Temperature	-10°C to +50°C
