5.2 Quick setup parameters (Virtual menu, shows when par. 17.2 = 1)
Code Parameter Min Max Unit Default ID Note
Motor nominal
voltage
180 690 V Varies 110
Check rating plate on the
motor.
Motor nominal
frequency
30.00 320.00 Hz
50.00 /
60.00
111
Check rating plate on the
motor.
Motor nominal
speed
30 20000 rpm
1440 /
1720
112
Default applies for a 4-
pole motor.
Motor nominal
current
0.2 x
I
Nunit
2.0 x
I
Nunit
A
I
Nunit
113
Check rating plate on the
motor.
Motor cos
0.30 1.00 0.85 120
Check rating plate on the
motor.
Current limit
0.2 x
I
Nunit
2.0 x
I
Nunit
A
1.5 x
I
Nunit
107 Maximum motor current
Torque boost 0 1 0 109
0 = Not used
1 = Used
P2.1
Remote control
place 1 selection
0 2 0 172
0 = I / O terminal
1 = Fieldbus
2 = Keypad
Start function
0
1 0 505
0 = Ramp
1 = Flying start
Stop function
0
1 0 506
0 = Coasting
1 = Ramp
Min frequency 0.00 P3.2 Hz 0.00 101 Minimum freq reference
Max frequency P3.1 320.00 Hz
50.00 /
60.00
102
Maximum freq refer-
ence
P3.3
Remote Control
Place 1 frequency
reference
selection
1 Varies 7 117
1 = Preset speed 0
2 = Keypad
3 = Fieldbus
4 = AI1
5 = AI2
6 = PID
7 = AI1 + AI2
8 = Motor potentiometer
9 = Pulse train / Encoder
10 = AIE1
11 = Temperature input 1
12 = Temperature input 2
13 = Temperature input 3
Note: Pay attention to DI/
Encoder switch position
when set with 9=Pulse
train / Encoder
Table 5: Quick setup parameters
P1.1
P1.2
P1.3
P1.4
P1.5

P1.7
P1.15
P2.2
P2.3
P3.1
P3.2

Vacon 20 Specifications

General

Communication Options	Modbus, CANopen, PROFIBUS, Ethernet
Protection Class	IP20
Power Range	0.25 to 18.5 kW
Control Method	Scalar control, Vector control
Ambient Temperature	-10°C to +50°C
