40 • vacon metasys n2
Tel.+358 (0)201 2121 • Fax +358 (0)201 212 205
7
APPENDIX 1
Process Data OUT (Slave to Master)
The Fieldbus Master can read the frequency converter’s actual values using process data variables.
Basic, Standard, Local/Remote Control, Multi-Step Speed Control, PID control and Pump and fan con-
trol
applications use process data as follows:
ID
Data
Value
Unit
Scale
2104 Process data OUT 1 Output Frequency Hz 0,01 Hz
2105
Process data OUT 2
Motor Speed
rpm
1 rpm
2106 Process data OUT 3 Motor Current A 0,1 A
2107 Process data OUT 4 Motor Torque % 0,1 %
2108 Process data OUT 5 Motor Power % 0,1 %
2109 Process data OUT 6 Motor Voltage V 0,1 V
2110 Process data OUT 7 DC link voltage V 1 V
2111
Process data OUT 8
Active Fault Code
-
-
Table 26. Process data OUT variables
The Multipurpose Control application has a selector parameter for every Process Data. The monitor-
ing values and drive parameters can be selected using the ID number (see NX All in One Application
Manual, Tables for monitoring values and parameters). Default selections are as in the table above.
Process Data IN (Master to Slave)
ControlWord, Reference and Process Data are used with All-inOne applications as follows:
Basic, Standard, Local/Remote Control and Multi-Step Speed Control applications
ID
Data
Value
Unit
Scale
2003 Reference Speed Reference % 0.01%
2001 ControlWord Start/Stop Command
Fault reset Command
- -
2004–2011 PD1 – PD8 Not used - -
Table 27.
