Appendix
0020297937_01 aroTHERM plus Installation and maintenance instructions 141
VWL 125/6 A
230V S3
VWL 125/6 A S3 VWL 155/6 A
230V S3
VWL 155/6 A S3
Water volume, in the outdoor unit
2.5 l 2.5 l 2.5 l 2.5 l
Water volume, in the heating circuit, minimum,
thawing mode, activated/deactivated back-up
heater
45 l / 150 l 45 l / 150 l 45 l / 150 l 45 l / 150 l
Remaining feed pressure, hydraulic
55.0 kPa
(550.0 mbar)
55.0 kPa
(550.0 mbar)
55.0 kPa
(550.0 mbar)
55.0 kPa
(550.0 mbar)
Technical data – Refrigerant circuit
VWL 45/6 A 230V
S3
VWL 55/6 A 230V
S3
VWL 65/6 A 230V
S3
VWL 85/6 A 230V
S3
Refrigerant, type
R290 R290 R290 R290
Refrigerant, fill quantity
0.60 kg 0.60 kg 0.90 kg 0.90 kg
Refrigerant, Global Warming Potential (GWP)
3 3 3 3
Refrigerant, CO
2
equivalent
0.0018 t 0.0018 t 0.0027 t 0.0027 t
Permissible operating pressure, maximum
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
Compressor, type
Rotary piston Rotary piston Rotary piston Rotary piston
Compressor, oil type
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Compressor, control
Electronic Electronic Electronic Electronic
VWL 125/6 A
230V S3
VWL 125/6 A S3 VWL 155/6 A
230V S3
VWL 155/6 A S3
Refrigerant, type
R290 R290 R290 R290
Refrigerant, fill quantity
1.30 kg 1.30 kg 1.30 kg 1.30 kg
Refrigerant, Global Warming Potential (GWP)
3 3 3 3
Refrigerant, CO
2
equivalent
0.0039 t 0.0039 t 0.0039 t 0.0039 t
Permissible operating pressure, maximum
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
3.15 MPa
(31.50 bar)
Compressor, type
Scroll compressor Scroll compressor Scroll compressor Scroll compressor
Compressor, oil type
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Specific
polyalkylene glycol
(PAG)
Compressor, control
Electronic Electronic Electronic Electronic
Technical data – Power, heating mode
VWL 45/6 A 230V
S3
VWL 55/6 A 230V
S3
VWL 65/6 A 230V
S3
VWL 85/6 A 230V
S3
Heat output, A2/W35
1.90 kW 1.90 kW 3.10 kW 3.10 kW
Coefficient of performance, COP, EN 14511,
A2/W35
3.70 3.70 4.10 4.10
Power consumption, effective, A2/W35
0.51 kW 0.51 kW 0.76 kW 0.76 kW
Power consumption, A2/W35
2.60 A 2.60 A 3.70 A 3.70 A
Heat output, minimum/maximum, A7/W35
2.10 … 6.50 kW 2.10 … 7.90 kW 3.00 … 8.50 kW 3.00 … 9.00 kW
Heat output, nominal, A7/W35
4.10 kW 4.20 kW 5.10 kW 7.80 kW
Coefficient of performance, COP, EN 14511,
A7/W35
4.60 4.40 4.70 4.40
Power consumption, effective, A7/W35
0.89 kW 0.95 kW 1.09 kW 1.77 kW
Power consumption, A7/W35
4.20 A 4.50 A 5.20 A 8.00 A
Heat output, A7/W45
3.10 kW 3.10 kW 4.20 kW 4.20 kW
Coefficient of performance, COP, EN 14511,
A7/W45
3.60 3.60 3.60 3.60
Power consumption, effective, A7/W45
0.86 kW 0.86 kW 1.17 kW 1.17 kW
Power consumption, A7/W45
4.00 A 4.00 A 5.40 A 5.40 A
