System overview of concentric system Ø110/160mm
10 Installation manual for the flue pipe for ecoTEC plus 0020137851_02
4
Elements Art. no.
0020166853 0020166854 0020166855 0020106380
mit
0020106376
Roof duct conc., 1000mm with rain
penetration collar,
Ø110/160
0020106408 X
Air clamp for Ø110/160, stainless
steel
0020143394 X
Pitched roof tile 25° - 50°, flexible,
black (RAL 9005)
0020106409 X X
Flat roof penetration collar
0020106411 X X
4.2 Elements (continued)
