Commissioning checklist 3
0020251823_01 System installation instructions 5
Work Comments/settings
51 Status Current value display (standby, heating, cooling, do-
mestic hot water)
52 Current flow temp. Current value display
53 Additional module
54 Status Current value display (standby, heating, cooling, do-
mestic hot water)
55 Current flow temp. Current value display
56 HEATING 1
57 Type of circuit Heating
58 Status Current value display (off, heating mode, cooling, do-
mestic hot water)
59 Target flow temp. Current value display
60 Max limit outs.temp. 21 °C, change in consultation with the customer, if re-
quired
61 Heating curve 0.4 to 0.6 for underfloor heating
62 Minimum temperature 15 °C
63 Maximum temperature 45 °C for underfloor heating
64 Auto Off mode Set-back
65 Room temp. mod. None if the control is installed in the heat pump
Temp. mod. if the control is installed in the living room
66 Cooling possible Yes for underfloor heating
No; you should not use passive cooling for compact col-
lectors and flat collectors
67 Min. cool. fl. tgt temp. 18 °C
68 End OT cooling 15 °C
69 Pump status Current value display: off / On
70 Dew point monitoring Yes
71 ZONE1
72 Zone activated Current value display: No / Yes
73 Day temperature 20 °C
74 Set-back temp. 15 °C
75 Room temperature Current value display
76 Zone assignment VRC 700
Condition: VRC 700 installed in the living room, room
temperature modulation activated
77 Zone valve status Current value display (closed/open)
78 Domestic hot water
79 Cylinder active Condition: Domestic hot water cylinder in the system
80 Target flow temp. Current value display
81 Domestic hot water 50 °C
Inform the end user about the anti-legionella function
82 Domestic hot water Current value display
83 Cyl. charging pump Current value display (off/on)
841 Circulation pump Current value display (off/on)
85 Anti-legionella day Selection: Off, Mo, Tu, We, Th, Fr, Sa, Su, Mo-Su
Factory setting: Off
86 Anti-legionella time 04:00
Depending on the customer
87 Cyl. boost hysteresis 15 K
88 Cylinder boost offset 10 K
89 Max. cyl. charg. time Off: KfW efficient house 40
60 min.: > KfW efficient house 40
