In the unlikely event of failure of the ignition
mechanism the pilot can be lit with a long
match or taper – See the next page.
When the pilot has lit keep the knob depressed
for about ten seconds to allow the flame sensing
probe to warm up.
The control knob can then be set to your preferred heat level. The settings are shown
in the table below:
OWNER GUIDE
Figure 3.
Control Knob
Position
Radiants Condition
2
Centre radiants on low. Outer radiants off.
(The right hand centre radiant will glow slightly
more than than the left hand centre radiant due
to the pilot flame)
3 Centre radiants fully on. Outer radiants off.
4 Centre radiants fully on. Outer radiants on low.
5 All radiants fully on.
© Baxi Heating U.K. Limited 2008.
Page 32
