4.10 Installation options.
In the United Kingdom, as supplied, the appliance can be installed in the following
situations: -
4.10.1 Conventional fireplace and hearth.
To a fireplace complete with surround and hearth as shown in figure 4 and complying
with BS1251 after removal of the fireback and sufficient material behind the fireback
for a debris catchment
space. The required
fireplace, hearth, debris
catchment area and
clearance dimensions
are shown in figure 5.
Page 14
© Baxi Heating U.K. Limited 2010.
Figure 5. Fireplace area
INSTALLER GUIDE
Figure 4. Hearth and fireplace opening dimensions
