CONTENTS
Section Heading Page
INSTALLER GUIDE 4 - 35
OWNER GUIDE 36 - 47
1. SAFETY AND UNPACKING 7
2. ACCESSORY LIST 8
3. APPLIANCE DATA AND EFFICIENCY 8
3.1 General information. 8
3.2 Efficiency. 8
4. GENERAL INSTALLATION REQUIREMENTS 9
4.1 Regulations, Standards and Law. 9
4.2 Ventilation requirements. 10
4.3 The Atmosphere sensing device (ASD). 10
4.4 Fireguard requirements. 10
4.5 Room considerations. 10
4.6 Chimney preparation. 11
4.7 Fireplace preparation. 11
4.8 The hearth. 12
4.9 Fireplace clearances. 12
4.10 Installation options. 14
4.10.1 Conventional fireplace and hearth. 14
4.10.1.1 ‘Hole-in-the-wall’ Installations. 15
4.10.2 Metal flue box and hearth. 15
4.10.3 Precast concrete or clay flue block system and hearth. 16
4.11 Flues. 16
4.12 Propane gas fires. 17
5. PACK CONTENTS 18
6. FIREPLACE CHECK 19
6.1 Soundness for appliance attachment. 19
6.2 Fireplace flue pull. 19
7. IGNITION CHECK 19
8. GAS SUPPLY CONNECTION 20
9. PREPARING APPLIANCE FOR INSTALLATION 20
10. HOTBOX INSTALLATION 24
10.1 Cable retention and floor fixing. 24
10.2 Sealing floor front - all installations. 26
Page 5
INSTALLER GUIDE
