17
5. SUPPLY GAS
Heater engine unit #534XAN is used with all natural gas installations.
Heater engine unit #534XAP is used with all propane installations.
The supply pressure must be between the limits shown in section 3.2 of this manual.
The supply connection is
3
/
8
’’NPT.
The opening for the gas supply line is at the rear left corner of the appliance.
6. PACK CONTENTS
See figure 19
#534XAN or #534XAP Engine unit
1 Appliance engine unit fitted with window
1 Ceramic ash bed
7 Ceramic logs
1 Firebox ceramic rear wall
2 Firebox ceramic sidewalls
1 Port cover
2 Frame side fixing brackets
1 Ash bed rear support
2 Restrictor plates type “A”
2 Restrictor plates type “B”
2 Restrictor plates type “C”
1 Gas inlet pipe connection adapter
1 Top heat shield panel with blanking plate
1 Frame top support angle
2 Stand-off brackets
2 Screws for wall switch plate
4 Screws for frame side fixing brackets
2 Screws for top heat shield panel
3 Screws for frame top support angle
6 Screws for standoff brackets
2 Screws for vent fixing
4 Woodscrews for fixing appliance to studding
1 Deluxe remote control
#601SFB Standard metal front (Alternative)
1 Upper louver unit
1 Lower louver unit
2 Side channels
2 Hinge studs
2 Hinge spacers
2 Magnet counter plates
#602CFB Cast iron front (Alternative)
1 Top casting unit
1 Bottom casting unit
#551DVK Standard horizontal through the wall vent
kit (Alternative to Dura-vent unit)
1 Vent pipe & terminal unit
2 Wall plates
2 Wall shields (Supplied flat)
12 Thread cutting screws
1 Styrofoam cutting support do-nut
8 Wood screws
8 Wall plugs
#755CFK Circulating fan kit (Additional option)
Details are with the kit
#603FSK Black or #604 Champagne Additional
optional 3 sided trims
1 Top trim
2 Side trims
2 Trim fixing brackets
2 Corner connection plates
8 Grub screws for corner connections
10 Screws for side trims & engine attachment
#605FSK Black or #606FSK Champagne Additional
optional 4 sided trims
2 Top & bottom trims
2 Side trims
2 Trim fixing brackets
4 Corner connection plates
16 Grub screws for corner connections
10 Screws for side trims & engine attachment
Take care when removing the contents from the packaging to prevent damage. Check that all the contents are in the packs and
are undamaged.
