Valor 534XAP Installation And Owner's Manual

7
Mantle depth “A” 1”
(25mm)
2”
(51mm)
3”
(76mm)
4”-5”
(102mm- 127mm)
6”
(152mm)
7”
(178mm)
8”–12”
(203mm-305mm) max.
Mantle clearance “B” 7”
(178mm)
8”
(203mm)
9”
(229mm)
10”
(254mm)
11”
(279mm)
12”
(305mm)
14”
(356mm)
Figure 1 Major dimensions & clearances without optional trims (Shown with #601SFB Front)
3 sided trims 4 sided trims
Figure 2 #601SFB Front with optional trims
3 sided trims 4 sided trims
Fi
gu
r
e
3
#60
2
C
FB Fr
o
n
t
w
i
t
h
opt
i
o
n
a
l
t
rim
s
