INSTALLER’S GUIDE
Page 5
1 APPLIANCE DATA
This product uses fuel effect pieces, burner compartment walls and gaskets containing
Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.
Excessive exposure to these materials may cause irritation to eyes, skin and respiratory
tract. Consequently, it is important to take care when handling these articles to ensure
that the release of dust is kept to a minimum. To ensure that the release of fibres from
these RCF articles is kept to a minimum, during installation and servicing we recommend
that you use a HEPA filtered vacuum to remove any dust and soot accumulated in and
around the fire before and after working on the fire. When replacing these articles we
recommend that the replaced items are not broken up, but are sealed within a heavy duty
polythene bag, clearly labelled as RCF waste. This is not classified as “hazardous waste”
and may be disposed of at a tipping site licensed for the disposal of industrial waste.
Protective clothing is not required when handling these articles, but we recommend you
follow the normal hygiene rules of not smoking, eating or drinking in the work area and
always wash your hands before eating or drinking.
This appliance does not contain any component manufactured from asbestos or asbestos
related products.
The appliance data label is located on a ‘pivot’ plate at the base of the fire. This can be
seen be pulling on the raised tab.
Gas Natural (G20)
Propane (G31)*
Inlet Pressure 20mbar 37mbar
Input - Max. (Gross) 6.85kW (23,400 Btu/h) 6.7kW (22,860 Btu/h)
Input - Min. (Gross) 2.7kW (9,410 Btu/h) 4.3kW (14,670 Btu/h)
Burner Test Pressure (Cold) 17.0 ± 0.75mbar (6.82 ±
0.3in w.g.)
35.85 ± 0.75mbar (14.4 ±
0.3in w.g.)
Gas Connection 8mm pipe 8mm pipe
Burner Injector Bray Cat. 18U Size 420 Stereomatic Size 170
Pilot & Atmosphere
Sensing Device
SIT Ref. OP NG9030 SIT Ref. OP LPG9222
Ignition Electronic
(Battery 9V PP3)
Electronic
(Battery 9V PP3)
Aeration Non-adjustable Non-adjustable
*When converted using kit 0591301.
