PICK-UP HITCH AND
LINKAGE
TO UNLOCK THE PICK-UP HITCH
1.
Push the lifting button to fully raise the linkage.
2.
Pull the hitch latch lever to unlatch the hitch. Keep the lever
pulled.
3.
Push the lowering button to lower the linkage. Release the
hitch latch lever when the hitch has passed the locking latch.
TO LOCK THE PICK-UP HITCH
4.
Push the lifting button until the hitch latches. You can hear a click
and the trailer hitch release lever jumps a little.
5.
Push the lowering button to lower the linkage slightly.
If the tractor is tted with hydraulic push-back hitch, you can move
the hitch forward and back with the button next right.
Make sure that the hitch is locked safely. The push-back hitch
will be locked only when in most up and forward position.
1 4
3 5
2
T/N Series Quick Guide / Direct
26
